Three Way Pneumatic Angle Seat Valve Manifold Valve Type Normally Open

Three Way Pneumatic Angle Seat Valve Manifold Valve Type Normally Open

    • Three Way Pneumatic Angle Seat Valve Manifold Valve Type Normally Open
    • Three Way Pneumatic Angle Seat Valve Manifold Valve Type Normally Open
  • Three Way Pneumatic Angle Seat Valve Manifold Valve Type Normally Open

    Product Details:

    Place of Origin: NINGBO
    Brand Name: Mkfale
    Certification: ISO9001
    Model Number: JDF1300

    Payment & Shipping Terms:

    Minimum Order Quantity: 1PC
    Price: Negotiation
    Packaging Details: Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice
    Delivery Time: Negotiation
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: Negotiation
    Contact Now
    Detailed Product Description
    Port Connection Type: Thread Port , Weld End Acting Type: Single Acting , Double Acting
    Body Material: SS304 , SS316 , SS316L Control Function: Normally Open , Normally Closed , Liberty
    Nominal Diameter: G1/2 , G3/4 , G1 Actuator Material: PA Actuator , SS Acutator , Aluminum Actuator
    High Light:

    pneumatic control valve

    ,

    pneumatic angle valve

    JDF1300 Pneumatically Operated 3 - Way Seat Valve Manifold Valve Type High Quality Mkfale





    3/2 - Way Seat Valve Pneumatically Operated , For Medium up to +180C , Manifold Valve Type , Threaded Port & Weld ends connection DN 15-25



    For mixing or distributing mediums ;

    Controlled by a pilot valve ;

    Flow optimized body in stainless steel ;

    Long Service life and maintenance - free operation .



    Port Connection Type

    T : Threaded port

    W : Weld end



    Acting Type

    S : Single Acting

    DS : Double Acting



    Body Material

    Blank : SS304 ( Standard )

    4 : SS316

    5 : SS316L



    Control Function

    NO : Normally Open

    NC : Normally Closed ( Standard )

    Na : Liberty



    Nominal Diameter

    15 : G1/2 , G3/4 , G1



    Actuator Material Code

    P : PA Actuator

    S : SS Actuator

    A : Aluminum Actuator



    Model

    JDF1300 : 3/2 - Way Seat Valve ( Manifold type )





    JDF1300 Series 3-Way seat valve consists of a pneumatically operated actuator and a 3-way valve body . The actuator is available in three different materials , PA , aluminum and stainless steel , Depending on the ambient temperature and customer requirements . Materials available for the valve body are stainless steel 304 , 316 and 316L . With our full range of compatible accessories , the mini-flange construction of the 3-way valve housing enables an unlimited number of the valves to be chained into linear groups , facilitating the neat and efficient layout of the pipeline system .



    Interchanging of pressure and service ports enables different fluidic circuit functions , such as mixing of distributing of the mediums . The flow – optimized valve body of JDF1300 allows excellent flow rates, The tried and tested self – Adjusting gland secures a high level of tightness and thus ensures reliable operation over years .



    For the user , the integrated valve design guarantees the neat and orderly installation of the equipment system , as well as economical benefits .





    FAQ



    Q: How much is our minimum order quantity ?
    A: Our minimun quantity is 1 Piece .



    Q: What ' s your business scope ?
    A: Our business scope is SMC type high quality cylinder , air source treatment , solenoid valve ,water valve,steam valve, mechnical valve ,foot valve,angle seat valve,anti-explosion valve,pluse vlave, pneumatic valve ,hydraulic ball valve,hydraulic ss ball valve,hydraulic check valve,hydraulic solenoid valve ,all type of coil,lubrication pump and parts,SS316 fitting,quick coupler , etc .



    Q: Could you offer the free samples ?
    A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.



    Q: What is the price of the product ?
    A: Our prices are based on the size and type of material , if you can give me the information ,
    then we can give you an estimated price is for reference only . We can do any size and any desgin .



    Q: what types of products you can make ?
    A: We can make many kinds of stainless steel materials and brass,aluminum . Valve / solenoid valve / electric valve / pneumatic valve and air cylinder products and so on .



    Why choose us



    1: Provide free products information .
    2: Reliable quality assured and active after-sell service
    3: One year quality guarantee
    4: Various style for each products and completely series pneumatic products .
    5: Large stock for fast shipping .
