SMTB General Purpose Stainless Steel Pressure Gauge Black Steel Case G / NPT / Other Thread

SMTB General Purpose Stainless Steel Pressure Gauge Black Steel Case G / NPT / Other Thread

SMTB General Purpose Stainless Steel Pressure Gauge Black Steel Case G / NPT / Other Thread

Product Details:

Place of Origin: China
Brand Name: Mkfale
Model Number: SMTB

Payment & Shipping Terms:

Minimum Order Quantity: 1 PC
Price: Negotiation
Packaging Details: Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice
Delivery Time: 5 - 30 Work Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: Negotiation
Contact Now
Detailed Product Description
Nominal Size: 40 , 50 , 63 , 75 , 100 , 150 , 200 , 250 Mm Accuracy Class: Class 2 . 5 / Class 1 . 6
Connection Size: G1 / 8 , G1 / 4 , G1 / 2 Or NPT Or Others Sensing Element: Copper Alloy
Connection: Brass Window: Acrylic Plastic / Instrument Glass

SMTB General Purpose Pressure Gauge SMTB Black Steel Case G / NPT / Other Thread








SMTB Black Steel Case General Purpose Pressure Gauge ,

SMCB Chromed Steel Case General Purpose Pressure Gauge ,

SMPB Plastic Case Steel Case General Purpose Pressure Gauge ,

SMTBS Steel Case Capsule Gauge ,

SMCBS Steel Case Capsule Gauge .




Technical Specification Table



GENERAL PURPOSE PRESSURE GAUGE SMTB Black Steel Case SMCB Chromed Steel Case SMPB Plastic Case
Application

SMTB,SMCB,SMPB series are the quality dry gauge designed to provide reliable serice on

non-corrosive and clean gaseous applications. The model are mostly used in manufacturing

or processing industrial,especially for pneumatics,,process,fabrication,compressed gas and

common industrial applicationl.

Features

Accuracy class 1.6 or 2.5, General industrial service application

Black steel case;chromed steel case;Plastic case.

Eelded back and front flange, Screw fastening case design

Over pressure up to 30% of Full Scale

Restrictor screw standard, Design scale ranges up to 600 bar

Technical Specification Nominal Size 40,50,63,75,100,150,200,250mm
Accuracy Class 40..75mm-Class 2.5, 100..250mm-class 1.6
Ingress Protection. IP32
Connection Size G1/8,G1/4,G1/2 or NPT or others.
Scale Range Pressure 0..600 bar, Vacuum -1 bar..0, Compound -1..24 bar
Filling Dry type
Tube Element Shape P≥100 bar in c tube, P>100 bar in helicoil
Operating Temperature Ambient temperature -10° ..+70° C, Medium temperature 70° C Max.
Operating Temperature

Additional error when pressure element tmperature

deviates from reference temperature +20° C(+68° F), be ±0.4%/10° C(50° F) rising or falling

Over Pressure Limit 130% of F.S.P≤100 bar, 115% of F.S.P>100bar
Dial Graduation Black graduation on white for single range, Black and red graduation on white for dual ranges
Design Material Casing and Bezel Ring Black Steel(SMTB series), Chromed steel(SMCB series), Plastic(SMPB series)
Casing and Bezel Ring Copper alloy
connection Brass
Window Acrylic plastic/Instrument glass
Window gasket Plastic
Pointer Black painted aluminium
Dial Plate Aluminium alloy
