Aluminium Housing Low Cost Pressure Transmitter , SMPB81 Series Pressure Transmitter With Display

Aluminium Housing Low Cost Pressure Transmitter , SMPB81 Series Pressure Transmitter With Display

Aluminium Housing Low Cost Pressure Transmitter , SMPB81 Series Pressure Transmitter With Display

Product Details:

Place of Origin: China
Brand Name: Mkfale
Model Number: SMPB8100

Payment & Shipping Terms:

Minimum Order Quantity: 1PC
Price: Negotiation
Packaging Details: Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice
Delivery Time: 5 - 30 Work Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: Negotiation
Contact Now
Detailed Product Description
Response Time: ≤ 10 Ms Operating Temp: - 20 To + 85 ℃
Output: 4 To 20mA ( Or 0 To 10mA , 1 To 5V , 0 To 5V , 0 To 10V ) Proof Pressure: 150 % FS
Electric Connection: M20 * 1 . 5 Male Power: 24VDC

Aluminium Housing Low Cost Pressure Transmitter , SMPB81 Series Pressure Transmitter With Display





Technical Specification Table


Type

SMPB8100
Accuracy0.25%F S,0.5%F S(including linearity.Hysteresis and repeatability)
Measuring Range-1 ... 0bar to -1...25bar,0... 0.1bar to 0... 600bar
LinearSuperior to 0.25%F S
1 year stabilitySuperior to 0.25%F S
Response time≤ 10 ms
Power supply24VDC (or 12 to 36VDC)
Output4 to 20mA(or 0 to 10mA,1 to 5V, 0 to 5V,0 to 10V)
Proof pressure150%F S
Burst pressure300%F S
Operating Temp-20 to +85℃
Compensated Temp-10 to +70℃
Storing Temp-40 to +125℃
Process connectionM20*1.5 male or 1/2NPT male
Electric connectionM20*1.5 male
Enclosure ProtectionIP65
Wetted partsSS304 SS316L
Diaphragm materialSS316L
Housing materialAluminium
Power Consume<0.5W(24VDC)
Weight720g





 Why choose us
1: Various style for each products and completely series industry instruments.
2: Customize according to your special request .
3: Provide free products information .
4: Reliable quality assured and active after-sell service
5: 12-18month quality guarantee

6: Large stock for fast shipping .



FAQ

Q: What ' s your business scope ?
A: High qulaity industry instruments is our business scope .Include Flow meter,Water meter,Manometer,Pressure ,Temperature,Level transimitter and parts.and industry Valve for water,anticorrosion fluid.
Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .


Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.

Q: What types of service ?
A: Supply technical information for your Working condition and give advise about details.
