Ex - Proof SMCL Electromagnetic Flow Meter With Zirconium Dioxide Liner Material

Ex - Proof SMCL Electromagnetic Flow Meter With Zirconium Dioxide Liner Material

Ex - Proof SMCL Electromagnetic Flow Meter With Zirconium Dioxide Liner Material

Product Details:

Place of Origin: China
Brand Name: Mkfale
Model Number: SMCL

Payment & Shipping Terms:

Minimum Order Quantity: 1 PC
Price: Negotiation
Packaging Details: Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice
Delivery Time: 5 - 30 Work Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: Negotiation
Contact Now
Detailed Product Description
Diameter: DN25 ~ DN350 Type: Normal , Ex - Proof
Structure: Compact Type , Remote Type Accuary: 0 . 5 %
Liner Material: Zirconium Dioxide ( ZrO2 ) Electrode Material: TiB2 ( Titanium Diboride )
Ground Ring: SUS316 , Hastelloy C , Titanium Power: AC100 ~ 240V , DC12 ~ 36V

Ex - Proof SMCL Electromagnetic Flow Meter With Zirconium Dioxide Liner Material








Technical Specification Table



SMCL

Ceramic Liner

Electromagnetic

Flow Meter

Integrated type
Nominal Diameter DN25~DN350
Type Normal,Ex-proof
Structure Type Compact type
Accuracy 0.5%
Liner material Zirconium Dioxide(ZrO2)
Electrode material TiB2 (Titanium diboride)
Ground Ring SUS316,Hastelloy C,Titanium
Min Electrical Conductivity 5μs/cm
Fluid Temperature -20℃~+180℃
Power Voltage AC100~240V, DC12~36V
Advantage Anti-Corrosion, Wear resistant ,Dirt resistance ,High temperature





Diameter H ( mm ) L ( mm ) W ( mm ) Size Weight kg
DN25 191 200 83 1 2.5
DN32 202 200 94 1 1 / 4 2.6
DN40 202 200 94 1 1 / 2 3
DN50 216 200 108 2 3.6
DN65 223 250 115 2 1 / 2 4.5
DN80 243 250 135 3 5.2
DN100 267 250 159 4 7
DN125 291 300 183 5 9.6
DN150 327 300 219 6 12.8
DN200 369 300 261 8 22





Why choose us



1: Sample order & small quantity order is acceptable .
2: Customize according to your special request .
3: Provide free products information .
4: Reliable quality assured and active after-sell service
5: 12-18month quality guarantee



FAQ



Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .

Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.

Q: What ' s your business scope ?
A: High qulaity industry instruments is our business scope .Include Flow meter,Water meter,Manometer,Pressure ,Temperature,Level transimitter and parts.and industry Valve for water,anticorrosion fluid.

Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .
