SMAPB6300 Small Steam Pressure Transmitter Liquid High Temperature Pressure Transmitter

SMAPB6300 Small Steam Pressure Transmitter Liquid High Temperature Pressure Transmitter

SMAPB6300 Small Steam Pressure Transmitter  Liquid High Temperature Pressure Transmitter

Product Details:

Place of Origin: China
Brand Name: Mkfale
Model Number: SMAPB6300

Payment & Shipping Terms:

Minimum Order Quantity: 1PC
Price: Negotiation
Packaging Details: Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice
Delivery Time: 5 - 30 Work Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: Negotiation
Contact Now
Detailed Product Description
Power Consume: < 0 . 5W ( 24VDC ) Electrical Connections: DIN43650 Plag Connector
Housing Material: Plastic Accuracy: 0 . 5 % F S , 1 % F S , 5 % F S
Linear: Superior To 0 . 5 % F S Response Time: ≤ 10ms

SMAPB6300 Small Steam Pressure Transmitter Liquid High Temperature Pressure Transmitter





Technical Specification Table



Type SMAPB6300
Accuracy 0.5%F S,1%F S,5%F S(including linearity.Hysteresis and repeatability
Measuring Range 0... 1bar to 0... 25bar
Linear Superior to 0.5%F S
Response time ≤10ms
Power supply 24VDC (or 12 to 36VDC)
Output 4 to 20mA
Load(Ω) <(u-12) / 0.02A
Proof pressure 150%F S
Burst pressure 300%F S
Operating Temp -20 to +85℃
Storing Temp -40 to +125℃
Process connection 1/2NPT male or 1/4NPT male or 1/8NPT male
Wetted parts SS304
Housing material Plastic
Electrical Connections DIN43650 Plag Connector
Power Consume <0.5W(24VDC)
Weight 170g




Why choose us

1: Various style for each products and completely series industry instruments.
2: Large stock for fast shipping .
3: High quality with competitive price .
4: Sample order & small quantity order is acceptable .
5: Customize according to your special request .


FAQ

Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .

Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.

Q: What ' s your business scope ?
A: High qulaity industry instruments is our business scope .Include Flow meter,Water meter,Manometer,Pressure ,Temperature,Level transimitter and parts.and industry Valve for water,anticorrosion fluid.

Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .




SMAPB6300 Small Steam Pressure Transmitter  Liquid High Temperature Pressure Transmitter
