|Place of Origin:||China|
|Minimum Order Quantity:||1 PC|
|Packaging Details:||Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice|
|Delivery Time:||5 - 30 Work Days|
|Payment Terms:||L/C, T/T, Western Union|
|Accuracy:||Better Than 1 %||Power:||220VAC ( Standard ) , 110VAC ( Optional )|
|Installation:||Clamp||Display:||Two Lines Displaying|
|Printing Output:||Built-in Thermal Printer||Communication:||MODBUS Protocol, FUJI Extension Protocol|
SMPUF Insertion Type Clamp On Ultrasonic Water Flow Meter Two Lines Displaying
Technical Specification Table
|SMPUF Portable Ultrasonic Flow Meter|
|Description||Can transfer the data to computer easily by serial interface
Battery powered last for over 14 hours continuous operation
Thickness gauge optional,thickness measurement achievable
Sensor:Sturdy and durable,Quickly install,High performance
With energy measurement function
|Application||SMPUF Portable Ultrasonic Flow meter/heat meter
is suitable for any industry application
of fluid flow/heat online calibration and measurement.
Good at easy operation,high accuracy,good consistency,
online printing,longer battery powered time,heat measurement,and so on.
Widely used in petrochemical,Metallurgy,Electricity,
Water supply,Water conservancy,Energy monitoring,etc.
|Accuracy||Better than 1%|
|Repeatability||Better than 0.2%|
|Measurement circle||500ms(Twice per second,one circle collect 128 group data)|
|Display||Two lines displaying(instant flow,total flow,signal status,etc)|
|MODBUS protocol, FUJI extension protocol|
|Printing Output||Built-in thermal printer.(Can realize the real-time printing or fixed time printing)|
|Data storage||Match with SD card data logger to store data of time, instantaneous flow,
total flow,signal status,etc. Can read the data on the computer(Can only
choose one from data storage and printing)
|Heat Function||Match with Pt100 clamp platinum resistor can realize the heat measuring|
|Other function||self-diagnose,indicate the working status whether normal|
Why choose us
1: Large stock for fast shipping .
2: High quality with competitive price .
3: Sample order & small quantity order is acceptable .
4: Customize according to your special request .
5: Provide free products information .
Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.
Q: What ' s your business scope ?
A: High qulaity industry instruments is our business scope .Include Flow meter,Water meter,Manometer,Pressure ,Temperature,Level transimitter and parts.and industry Valve for water,anticorrosion fluid.
Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .
Q: What types of service ?
A: Supply technical information for your Working condition and give advise about details.
