High Performance Water Solenoid Valve For Refrigeration Compressor Group Etc

High Performance Water Solenoid Valve For Refrigeration Compressor Group Etc

    • High Performance Water Solenoid Valve For Refrigeration Compressor Group Etc
    • High Performance Water Solenoid Valve For Refrigeration Compressor Group Etc
    • High Performance Water Solenoid Valve For Refrigeration Compressor Group Etc
    • High Performance Water Solenoid Valve For Refrigeration Compressor Group Etc
  • High Performance Water Solenoid Valve For Refrigeration Compressor Group Etc

    Product Details:

    Place of Origin: China
    Brand Name: Mkfale
    Model Number: SM

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 PC
    Price: Negotiation
    Packaging Details: Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice
    Delivery Time: 5 - 30 Work Days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: Negotiation
    Contact Now
    Detailed Product Description
    Refrigerant: R12 , R22 , R134a , R404 , R407C , R410 , R502 Media Temperature: - 30 ℃ ~ + 105 ℃
    Service: 100 , 000 Cyeles Working Pressure: 3 . 0 MPa
    Operating Principles: Direct Acting , Diaphragm Pliot Operated Port Size (mm): 2 . 5 , 7 . 0 , 12 . 5 , 16 . 5 , 25 . 5

    High Performance Water Solenoid Valve For Refrigeration Compressor Group Etc








    Porduct Introduction



    This Solenoid Valve is an automatic control parts used in liquid line,suction line and steam line of refrigeration system to control the refrigerant to pass or not pass , the valve is widely used in refrigeration compressor group , central air-conditioning , coldstorage equipment and bus air - conditioning system ..




    Technical Parameters



    Refrigerant R12 , R22 , R134a , R404 , R407C , R410 , R502
    Media Temperature 30 ℃ ~ + 105 ℃
    Service 100,000 cyeles
    Working Pressure 3 . 0 MPa






    Model Operating
    Principles
    Port Size
    (mm)
    Connection Size Opening Pressure
    Differential(bar)
    KV factor
    (m3/h)
    SAE(in) ODF Min MOPD
    in. mm
    SM-1020/2 Direct
    Acting
    2.5 1/4"     0 21 0.175
    SM-1020/3 3/8"     0.23
    SM-1028/2 - 1/4"   0.15
    SM-1028/3 - 3/8"   0.23
    SM-1064/3 Diaphragm
    Pliot Operated
    7 3/8" -   0.05 0.8
    SM-1064/4 1/2" -
    SM-1068/3 - 3/8"
    SM-1068/4 - 1/2"
    SM-1070/4 12.5 1/2" -   2.2
    SM-1070/5 5/8"     2.61
    SM-1078/4   1/2"   2.2
    SM-1078/5   5/8" 16 2.61
    SM-1078/6   3/4"
    SM-1079/7   7/8" 22
    SM-1098/6 16.5   3/4"   4.8
    SM-1098/7   7/8" 22 5.7
    SM-1099/9   1-1/8"
    SM-1078/9 25.5   1-1/8"   10
    SM-1079/11   1-3/8" 35



    Why choose us


    1: Sample order & small quantity order is acceptable .
    2: Customize according to your special request .
    3: Provide free products information .
    4: Reliable quality assured and active after-sell service
    5: 12-18month quality guarantee




    FAQ


    Q: What ' s your business scope ?
    A: High qulaity industry instruments is our business scope .Include Flow meter,Water meter,Manometer,Pressure ,Temperature,Level transimitter and parts.and industry Valve for water,anticorrosion fluid.

    Q: What is the price of the product ?
    A: Our prices are based on the size and type of material , if you can give me the information ,
    then we can give you an estimated price is for reference only . We can do any size and any desgin .



    Q: Could you offer the free samples ?
    A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.


    Q: What types of service ?
    A: Supply technical information for your Working condition and give advise about details.



    High Performance Water Solenoid Valve For Refrigeration Compressor Group Etc
