SMRT Variable Area Flow meter LCD Display With 4-20mA Displacement With Anti Corrosive

SMRT Variable Area Flow meter LCD Display With 4-20mA Displacement With Anti Corrosive

    • SMRT Variable Area Flow meter LCD Display With 4-20mA Displacement With Anti Corrosive
    • SMRT Variable Area Flow meter LCD Display With 4-20mA Displacement With Anti Corrosive
  • SMRT Variable Area Flow meter LCD Display With 4-20mA Displacement With Anti Corrosive

    Product Details:

    Place of Origin: China
    Brand Name: Mkfale
    Model Number: SMRT

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 PC
    Price: Negotiation
    Packaging Details: Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice
    Delivery Time: 5 - 30 Work Days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: Negotiation
    Contact Now
    Detailed Product Description
    Power: 24VDC 、 220VAC Alarm Selection: K1 、 K2 : ( SC 3 . 5 - NO )
    Ex - Proof Type: ExiaⅡ CT4 Body Material: SS304 、SS316L Liner : PTFE
    Medium: Air ( Gas Damper For Option ) , Water Design Selection: Z : Pointer , D : LCD

    SMRT Variable Area Flow meter LCD Display With 4-20mA Displacement With Anti Corrosive








    Technical Specification Table



    Description :

    SM series Variable area Flowmeter, has simple structure, reliable operation, wide applicable

    scope, high precision, easy installation, etc,.Compared with glass tube rotameter, the series of

    flowmeter with high pressure, high temperature resistance, strong security, simple reading and so on.And can be used with opaque medium and corrosive medium flow measurement.Instrument tube body and the flange is made of stainless steel (316L or 1 Cr18Ni9Ti). The conventional orifice, the float is made of stainless steel, corrosion of the orifice plate, float and pipe body lined with PTFE anti-corrosion materials.



    Measure Principle :

    Variable area flowmeter, namely in the vertical measure tube,when fluid through a pipe upwards,

    float up, lift and float at a particular location float suffered gravity balance, the float and orifice (or

    taper pipe) flow between keeping clearance area.Clearance area is proportional to the higher level of float, namely the size of the float a highly representative of the flow.Float up and down, in the form of a magnetic coupling transfer position to the external indicators, making the indicator pointer following the float, and with the help of a CAM plate to make the size of the pointer to indicate linear flow value.



    Design selection :

    Z: Pointer, D: LCD



    Medium :

    Air(Gas damper for option), Water



    Body Material :

    SS304,SS316L Liner:PTFE



    Remote transmitter selection :

    Es1 electricity remote transmit:0~10mA DC three wire

    Es2 electricity remote transmit:4~20mA DC two wire



    Ex-proof type :

    ExiaⅡ CT4 , ExdⅡ CT4



    Measure tube special requirement :

    Warmkeeper



    Alarm Selection :

    K1 , K2 : ( SC3 . 5 – NO)



    Power :

    24VDC,220VAC



    Installation :

    Bottom to top;Bottom to top side;Bottom side to top side;Left to right;Right to left;



    Why choose us


    1: Various style for each products and completely series industry instruments.

    2: Customize according to your special request .
    3: Provide free products information .

    4: Large stock for fast shipping .
    5: High quality with competitive price .



    FAQ



    Q: How much is our minimum order quantity ?
    A: Our minimun quantity is 1 Piece .

    Q: Could you offer the free samples ?
    A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.



    Q: What is the price of the product ?
    A: Our prices are based on the size and type of material , if you can give me the information ,
    then we can give you an estimated price is for reference only . We can do any size and any desgin .

    Q: What types of service ?
    A: Supply technical information for your Working condition and give advise about details.
