Central Strainer Instrument Flow Meter With External Regulating Device SMSC - 15E ~ 50E

Central Strainer Instrument Flow Meter With External Regulating Device SMSC - 15E ~ 50E

Central Strainer Instrument Flow Meter With External Regulating Device SMSC - 15E ~ 50E

Product Details:

Place of Origin: China
Brand Name: Mkfale
Model Number: SMSC - 15E ~ 50E

Payment & Shipping Terms:

Minimum Order Quantity: 1 PC
Price: Negotiation
Packaging Details: Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice
Delivery Time: 5 - 30 Work Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: Negotiation
Contact Now
Detailed Product Description
Features: Magnetic Shield , Use For External Magnetic Field Protection Temperature: ≤ 40 ℃
Pressure: 1 . 6 MPa Options: Meter Equipped With Read Switch Is Available
Installation Requirement: Pipeline Must Be Flushed Before Intallation Nominal Diameter: DN15 , DN20 , DN25 , DN32 , DN40 , DN50

SMSC - 15E ~ 50E With External Regulating Device , Central Strainer Instrument Flow Meter






Technical  Specification Table





Application Measuring the volume of cold potable water passing through the pipeline
Working Conditions

Water temperature : ≤ 40 ℃

Water Pressure : ≤ 1 . 6 MPa

Features

1 . With external regulating device

2 . Magnetic drive , lower transmission resistance

3 . Magnetic Shield , use for external magnetic field protection

4 . Evacuated and sealed dry dial register ensures clear reading

5 . Central strainer

6 . Inlet Strainer

7 . There are two versions DN50 meter body to be chsen ; with threaded ends or flanged ends

Compliance with Standard Technical data conforms to ISO 4064 Class B Standard for horizontal installation
Options

Meter with non return valve ( different price ) is available except SMSC - 50E

Meter for hot water up to 90 ℃ is available

Meter equipped with read switch is available

Installation Requirements

The meter should be installed in horizontal position with the register face upwards

Pipeline must be flushed before installation

The meter should be constantly full of water during operation



Main Technical Date



Nominal Diameter DN 15 20 25 32 40 50
Maximum Flow Rate m³ / h Qmax 3 5 7 12 20 30
Nominal Flow Rate m³ / h Qn 1.5 2.5 3.5 6 10 15
Transition Flow Rate l / h Qt 120 200 280 480 800 3000
Minimum Flow Rate l / h Qmin 30 50 70 120 200 450
Maximum Reading m³ 99999.99995 999999.99995/999999.9995
Minimum Reading m³ 0.000 05 0.00005/0.0005



Maximum Permissible Error



In the lower zone from Qmin inclusive up to but excluding Qt is ± 5 %

In the upper zone from Qt inclusive up to and including Qmax is ± 2 %



Dimension Picture



Nominal diameter and arrow are indicated on the side of the meter body .

Arrow is indicated on the other side . The lid can open more than 180 ° .
