Custom Ultrasonic Liquid Flow Meter , Digital Flow Meter For Water Management

Custom Ultrasonic Liquid Flow Meter , Digital Flow Meter For Water Management

Custom Ultrasonic Liquid Flow Meter , Digital Flow Meter For Water Management

Product Details:

Place of Origin: China
Brand Name: Mkfale
Model Number: SMFUF

Payment & Shipping Terms:

Minimum Order Quantity: 1 PC
Price: Negotiation
Packaging Details: Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice
Delivery Time: 5 - 30 Work Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10000 PCS / Year
Contact Now
Detailed Product Description
Accuracy: Better Than 1 % Repeatability: Better Than 0 . 2 %
Measurement Circle: 500ms Max Flow Velocity: 64m / S
Pipe Material: Carbon Steel, Stainless Steel, Cast Iron, Etc Pipe Liner Material: Exoxyasphalt, Rubber,Slurry, Polypropylene, Etc

Custom Ultrasonic Liquid Flow Meter , Digital Flow Meter For Water Management







Water Electromagnetic Flow meter , Ceramic Liner electromagnetic flow meter , Sanitary electromagnetic flow meter , Ultrasonic level meter , Mass flow meter , Variable area flow meter ( Metal Rota Meter ) , Stainless steel Gauge ,  Bimetal thermometer,pressure transmitter , level transmitter , Temperature transmitter , needle valve , Water solenoid Valve



Why choose us



1: Large stock for fast shipping .

2: Provide free products information .
3: Reliable quality assured and active after-sell service
4: High quality with competitive price .
5: Sample order & small quantity order is acceptable .



FAQ



Q: What ' s your business scope ?
A: High qulaity industry instruments is our business scope .Include Flow meter,Water meter,Manometer,Pressure ,Temperature,Level transimitter and parts.and industry Valve for water,anticorrosion fluid.



Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.


Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .



Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .



Technical Specification Table



SMFUF Fixed Ultrasonic Flow Meter Integrated type
Repeatability Better than 0.2%
Measurement circle 500ms(Twice per second,one circle collect 128 group data)
Max Flow velocity 64m/s (velocity resolution 0.001m/s)
Data Storage Optional built-in data logger (SD card) can record date,instantaneous flow,
accumulative flow,signal condition etc. Can import data by special software
to computer which is convenient for statistics and management.
Communication
protocol
MODBUS, M-BUS, FUJI Extension protocol,and compatible with some other
similar products,protocol made by other China manufacturers
Medium Water,sea water,sewage,alcohol,all kinds of oil and other single,uniform,
stable liquid which can transmit ultrasonic wave
Viscosity ≤20000ppm with less bubble
Signal Cable SEYV75-2 type special shielded cable, single line can be lengthened to 500m,
Metal sleeve is needed when cabling to increase anti-interference performance,
Please noted cable shouldn’t parallel with the high tension line,and should
avoid the frequency converter or other interference sources.



Description :



Automatically record positive/negative/net accumulative flow of the past 512 days,

the past 128months and the past 10years

Automatically record on/off power and flow rate of the last 30times and can

achieve add the flow rate automatically or manually,read by MODBUS protocol

Can program batch (quantitative) controller,with self-diagnosis function

Can achieve software update by code file sent via Email

Dynamic response speed:0.004s

DPS digital signal processing technology,high anti-interference ability

Time resolution 10ts, High accuracy flow measurement,accuracy can be 0.5% class

Heat and cold measurement

Circuit board welding adopt international advanced SMD automatic welding process

CNC precision machining aluminium alloy housing material



Application :



SMFUF Series FixedType Ultrasonic Flow Meter is widely used

for online flow measurent of various industrial liquied.

Transmitter type: wall mounted A type, Wall mounted B type, wall mounted explosion type,

Panel type, local display type (F4 type transmitter) and module type;

Transducer type:clamp-on,insertion and pipeline type.



Accuracy :



Better than 1%



Display :



2*10 English backlight LCD can display instantaneous flow and positive,

negative,net accumulative flow, flow velocity etc.



Operation :



4*4 touch keyboard operation (F4 transmitter magnetic buttons)



Input Signal :



Three way 4-20mA analog input,accuracy up to 0.1% Can input pressure,level,

temperature and other signal Two way three-wire Pt100 temperature sensor



Pipe Material :



Carbon steel, Stainless steel, Cast iron, Coper, PVC, Aluminum,

FRP and other uniform pipeline, Liner is allowable



Pipe Liner Material :



Exoxyasphalt, Rubber,Slurry, Polypropylene, Polystyrene, Bakdlite, Ptfe etc



Custom Ultrasonic Liquid Flow Meter , Digital Flow Meter For Water Management
