Remote Separate Type Vortex Steam Flow Meter 24VDC Power Full SS304 Non Streamline

Remote Separate Type Vortex Steam Flow Meter 24VDC Power Full SS304 Non Streamline

Remote Separate Type Vortex Steam Flow Meter 24VDC Power Full SS304 Non Streamline

Product Details:

Place of Origin: China
Brand Name: MKfale
Model Number: SMVF Remote

Payment & Shipping Terms:

Minimum Order Quantity: 1 PC
Price: Negotiation
Packaging Details: Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice
Delivery Time: 5 - 30 Work Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: Negotiation
Contact Now
Detailed Product Description
Normally: -40℃~350℃ Body Material: Cast Steel; Stainless Steel 304 / 316L
Power: 24VDC Measured Medium: Liquid; Common Gas; Saturated Steam; Superheated Steam; Others
Main Body: Precesion Casting Technology Construction: Adopt Built - In Sensor Structure

SMVF Vortex Flow Meter Remote Separate Type 24VDC Power Gas , Liquid , Steam Flow Meter







Technical Specification Table



Nominal Diameter 25 32 40 50 65 80 100 125
Water 1.3~15 1.5~16 3~33 4~44 6~66 13~140 20~220 36~400

Standard Measuring

Range(m3/h)

Normal pressure and temperature air(NPT air) 8~100 14~350 18~450 30~750 50~1250 70~1750 100~2500 200~5000

Standard Measuring

Range(m3/h)



Nominal Diameter 150 200 250 300
Water 50~600 100~1200 150~1800 200~2400

Standard Measuring

Range(m3/h)

Normal pressure and temperature air(NPT air) 400~10000 600~15000 1000~25000 -

Standard Measuring

Range(m3/h)





SMVF Vortex Flow Meter :

Remote separate type



Description



Normally:

-40℃~350℃



Communication:

HART,RS485



Brand new digital processing calculation,

enjoy excellent anti-vibration & anti-interference performance

Adopt built-in sensor structure ,better protect the flow sensor

Flow sensor embedded temperature sensor ,reduce the leakage point

Main body adopt precesion casting technology ,stronger swirl generating body



Nominal Diameter :

DN10~DN300(Flange and water), DN100~DN3000(Insertion)



Body Material :

Cast steel; SS304; SS316L



Connection Type :

Flange; Wafer; Insertion; Others



Power :

24VDC



Special Mark :

Blank: Common; M: Standard Signal Output; B: Intrinsically Safe Explosion-proof

X: On Site Display; G: High Temperature(350℃)

W: Temperature Compensation; Y: Pressure Compenstion

Z: Temperature & Pressure Compensation



Measured Medium :

Liquid; Common Gas; Saturated Steam; Superheated Steam; Others





FAQ



Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.



Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .


Q: What ' s your business scope ?
A: High qulaity industry instruments is our business scope .Include Flow meter,Water meter,Manometer,Pressure ,Temperature,Level transimitter and parts.and industry Valve for water,anticorrosion fluid.

Q: What types of service ?
A: Supply technical information for your Working condition and give advise about details.



Why choose us



1: High quality with competitive price .
2: Sample order & small quantity order is acceptable .
3: Customize according to your special request .
4: Provide free products information .
5: Reliable quality assured and active after-sell service
