SMVF Series Insertion Vortex Flow Meter For Big Diameter Pipeline With - 40 ℃ ~ 350 ℃

SMVF Series Insertion Vortex Flow Meter For Big Diameter Pipeline With - 40 ℃ ~ 350 ℃

SMVF Series Insertion Vortex Flow Meter For Big Diameter Pipeline With - 40 ℃ ~ 350 ℃

Product Details:

Place of Origin: China
Brand Name: Mkfale
Model Number: SMVF

Payment & Shipping Terms:

Minimum Order Quantity: 1PC
Price: Negotiation
Packaging Details: Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice
Delivery Time: 5 - 30 Work Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: Negotiation
Contact Now
Detailed Product Description
Type: Integrated Type Normally: - 40 ℃ ~ 350 ℃
Communication: HART , RS485 Body Material: Cast Steel , Stainless Steel 304 , 316L
Connection Type: Flange ; Wafer ; Insertion ; Others Power: 24VDC

SMVF Series Integrated Type 24VDC Power Vortex Flow Meter - 40 ℃ ~ 350 ℃







Description



Normally:-40℃~350℃

Communication: HART,RS485

Brand new digital processing calculation,

enjoy excellent anti-vibration & anti-interference performance

Adopt built-in sensor structure ,better protect the flow sensor

Flow sensor embedded temperature sensor ,reduce the leakage point

Main body adopt precesion casting technology ,stronger swirl generating body



Flange/Wafer Type



Size : 15 20 25 32 40 50 65 80 100 125 150 200 250 300

Mark No . : 150 200 250 320 400 500 650 800 101 125 151 201 251 301



Insertion Type



Size : 100 , 125 , 150 , 200 , 250 , 300 , 350 , 400 , 500 , 600 , 700 , 800 , 900 , 1000 , 1200 , 1400 , 1600 , 1800 , 2000



Mark No . : 100 , 125 , 151 , 201 , 251 , 301 , 351 , 401 , 501 , 601 , 701 , 801 , 901 , 102 , 122 , 142 , 162 , 182 , 201



Nominal Diameter : 25 , 32 , 40 , 50 , 65 , 80 , 100 , 125 , 150 , 200 , 250 , 300



Water :

Standard Measuring Range(m3/h) : 1.3~15 , 1.5~16 , 3~33 , 4~44 , 6~66 , 13~140 , 20~220 , 36~400 , 50~600 , 100~1200 , 150~1800 , 200~2400



Normal pressure and temperature air(NPT air) :

Standard Measuring Range(m3/h) : 8~100 , 14~350 , 18~450 , 30~750 , 50~1250 , 70~1750 , 100~2500 , 200~5000 , 400~10000 , 600~15000 , 1000~25000



Technical Specification Table



Nominal Diameter DN10~DN300(Flange and wafer), DN100~DN3000(Insertion)
Body Material Cast steel; SS304; SS316L
Connection Type Flange; Wafer; Insertion; Others
Power 24VDC
Special Mark

Blank: Common; M: Standard Signal Output; B: Intrinsically Safe Explosion-proof

X: On Site Display; G: High Temperature(350℃)

W: Temperature Compensation; Y: Pressure Compenstion

Z: Temperature & Pressure Compensation

Measured Medium Liquid; Common Gas; Saturated Steam; Superheated Steam; Others



Water Electromagnetic Flow meter , Turbine flow meter , Ultrasonic flow meter , Ultrasonic level meter , Mass flow meter , Variable area flow meter ( Metal Rota Meter ) , level transmitter , Temperature transmitter , needle valve , Steam Solenoid Valve



Why choose us


1: Various style for each products and completely series industry instruments.
2: Large stock for fast shipping .

3: Sample order & small quantity order is acceptable .
4: Customize according to your special request .
5: Provide free products information .





FAQ



Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .



Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .



Q: What types of service ?
A: Supply technical information for your Working condition and give advise about details.


Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.
