SMCL Remote Separate Type Ceramic Liner Electromagnetic Flow Meter
Technical Specification Table
SMCL Ceramic Liner Electromagnetic Flow Meter :
Remote separate type
Nominal Diameter :
DN25~DN350
Type :
Normal , Ex - proof
Structure Type :
Remote type
Accuracy :
0.5%
Liner material :
Zirconium Dioxide ( ZrO2 )
Electrode material :
TiB2 ( Titanium diboride )
Ground Ring :
SUS316 , Hastelloy C ,Titanium
Min Electrical Conductivity :
5μs / cm
Fluid Temperature :
- 20 ℃ ~ + 180 ℃
Power Voltage :
AC100 ~ 240V , DC12 ~ 36V
Advantage :
Anti-Corrosion , Wear resistant , Dirt resistance , High temperature
| Diameter |
H ( mm ) |
L ( mm ) |
W ( mm ) |
Size |
Weight kg |
| DN25 |
191 |
200 |
83 |
1 |
2.5 |
| DN32 |
202 |
200 |
94 |
1 1 / 4 |
2.6 |
| DN40 |
202 |
200 |
94 |
1 1 / 2 |
3 |
| DN50 |
216 |
200 |
108 |
2 |
3.6 |
| DN65 |
223 |
250 |
115 |
2 1 / 2 |
4.5 |
| DN80 |
243 |
250 |
135 |
3 |
5.2 |
| DN100 |
267 |
250 |
159 |
4 |
7 |
| DN125 |
291 |
300 |
183 |
5 |
9.6 |
| DN150 |
327 |
300 |
219 |
6 |
12.8 |
| DN200 |
369 |
300 |
261 |
8 |
22 |
Why choose us
1: Various style for each products and completely series industry instruments.
2: Large stock for fast shipping .
3: High quality with competitive price .
4: Sample order & small quantity order is acceptable .
5: Customize according to your special request .
FAQ
Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .
Q: What types of service ?
A: Supply technical information for your Working condition and give advise about details.
Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .
Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.
