Portable Digital Pressure Transmitter SMPB8303 Series 4 to 20mA , Output Response Time 10 ms
Technical Specification Table
|
SMPB83 SERIES PRESSURE
TRANSMITTER
|
SMPB8303 |
| Accuracy |
0.25%F S,0.5%F S(including linearity.Hysteresis and repeatability |
| Measuring Range |
-1 ... 0bar to -1...25bar,0... 0.1bar to 0... 600bar |
| Linear |
Superior to 0.25%F S |
| 1 year stability |
Superior to 0.25%F S |
| Response time |
≤ 10ms |
| Power supply |
24VDC (or 12 to 36VDC) |
| Output |
4 to 20mA |
| Load(Ω) |
＜(u-12) / 0.02A |
| Proof pressure |
150%F S |
| Burst pressure |
300%F S |
| Operating Temp |
-20 to +85℃ |
| Compensated Temp |
-10 to +70℃ |
| Storing Temp |
-40 to +125℃ |
| Process connection |
M20*1.5 male or 1/2NPT male |
| Enclosure Protection |
IP65 |
| Wetted parts |
SS304 |
| Diaphragm material |
SS316L |
| Housing material |
Plastic |
| Power Consume |
<0.5W(24VDC),DIN43650 Plag Connector |
| Local indicator |
LED |
| Weight |
320g |
