SMCG Series Coriolis Mass Flow Meter Accuracy ± 0 . 50 % Process , 10MPa Pressure DN15 - DN100

SMCG Series Coriolis Mass Flow Meter Accuracy ± 0 . 50 % Process , 10MPa Pressure DN15 - DN100

SMCG Series Coriolis Mass Flow Meter Accuracy ± 0 . 50 % Process , 10MPa Pressure DN15 - DN100

Product Details:

Place of Origin: China
Brand Name: Mkfale
Model Number: SMCG

Payment & Shipping Terms:

Minimum Order Quantity: 1PC
Price: Negotiation
Packaging Details: Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice
Delivery Time: 5 - 30 Work Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: Negotiation
Contact Now
Detailed Product Description
Nominal Size: DN15~DN100 Flow Accuracy: ± 0 . 50 %
Dens. Accuracy: ± 2kg / M³ Temp. Range: - 40 ~ 250 °C
Process Pressure: ≤ 10MPa Power Supply: 24V DC , 220V AC

SMCG Series Coriolis Mass Flow Meter Accuracy ± 0 . 50 % Process , 10MPa Pressure DN15 - DN100








SMCG Series Coriolis Mass Flow Meter


Including SMCG series Sensor and SMIPT Transmitter, SMCG Series Coriolis Mass Flow Meter with the
measuring accuracy is of ±0.50%.



Advantages & Characteristics



Applying double V type flow tubes designing, increasing the operating frequency and
lowering the outside oscillating influence at low frequency, diminishing the installation size;



Supplying the complete measurements of mass flow, volume flow, density, temperature and
calculated parameters, you can receive the reliable measured results without any complicated
calculation, which can directly replace the volume meter;



Ease of installation without rectification and filtering parts, no need special installation
required straight pipes;



No moving parts and no need frequent maintenance; no need to be dismounted frequently for
calibration because of high stable performance;



Compact installation to save the installation costs;



Can directly connect with the master pipe to measure the density, as well as measuring
density through by-pass pipeline with self-draining function. Because this installation can
adjust flow rate and reduce abrasion, the density of liquid mixed solid particles or density of
slurry can be measured;



Can be directly applied in the fields of using volume meter or densimeter because of its
higher cost performance;



Being widely used in food industries because of its self-draining characteristics.




Sensor



Nominal Size Flow Accuracy Dens . Accuracy Temp . Range Process Pressure Measuring Tubes Transmitter
DN15 ~ DN100 ± 0 . 5 0% ± 2 kg / m ³ - 40 ~ 250 ℃ ≤ 10 MP 316L IPT100





Transmitter



Installation Type Power Supply Current Output Frequency Output Digital Comm.

Human-machine

Interface

Ex-mark

Compact

Remote

24V DC

220V AC

4~20mA(active, the

output variables can

be configured)

0~10KHz(active or passive,the

output variables can be

configured )

RS-485/Modbus

HART/FF

(optional)

3 photoelectric keys,

2 lines LCD,

configuration, check,

zero calibration

Exde[ib]I

ICT6
