Digital Liquid Filled Pressure Gauge / Liquid Filled Oil Pressure Gauge Back And Bottom Entry

Digital Liquid Filled Pressure Gauge / Liquid Filled Oil Pressure Gauge Back And Bottom Entry

Digital Liquid Filled Pressure Gauge / Liquid Filled Oil Pressure Gauge Back And Bottom Entry

Product Details:

Place of Origin: China
Brand Name: Mkfale
Model Number: SM1SB

Payment & Shipping Terms:

Minimum Order Quantity: 1PC
Price: Negotiation
Packaging Details: Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice
Delivery Time: 5 - 30 Work Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: Negotiation
Contact Now
Detailed Product Description
Nominal Size: 63 , 100 , 150mm Accuracy Class: Class 1 . 6 , Class 1 . 0 ( Φ > 100mm )
Connection Size: G1 / 4 , G1 / 2 Or NPT Filling: Dry Or Liquid Filled
Connection: Brass Window: Tempered Glass

Digital Liquid Filled Pressure Gauge / Liquid Filled Oil Pressure Gauge Back And Bottom Entry







ONE PIECE CONNECTION STAINLESS STEEL CASE DESIGN



SM1SB One piece connection with bayonet case design




Application



A special design with stainless steel case and copper alloy wetted part and fillable option for

extreme vibration aplication and non-corrosive ambient field condition,with bayonet lock

case design.applicable for pneumatic and hydraulic systems, compressors, engines, pumps,

sprinkles system,building automation system and processing unit where vibration is

concern.



Features



Accuracy class 1.6,class 1.0, Wide range vibration application

Stainless steel case design, Knock-down system back and front flange

Crimped lock case design, Over pressure up to 30% of Full Scale

Restrictor screw standard, Excellent vibration resist with liquid filling

Design scale ranges up to 600 bar



Technical Specification



Nominal Size :



63 , 100 , 150mm



Accuracy Class :



Class 1 . 6 , Class 1 . 0 ( Φ > 100mm )



Ingress Protection . :



IP65 ( Weather tight )



Connection Size :



G1 / 4 , G1 / 2 or NPT



Scale Range :



Pressure 0 .. 1000 bar , Vacuum - 1 bar .. 0 , Compound – 1 .. 24 bar



Tube Element Shape :



P ≤ 100 bar in c tube , P > 100 bar in helicoil



Filling :



Dry or liquid filled



Operating Temperature :



Ambient temperature – 10 ° .. + 70 ° C , Medium temperature 90 ° C Max .



Temperature Error :



Additional error when pressure element temperature deviates from reference temperature + 20 ° C ( + 68 ° F ) , be ± 0 . 4 % / 10 ° C (50 ° F ) rising or falling



Over Pressure Limit :



130 % of F . S . P ≤ 100 bar , 115 % of F . S . P > 100bar



Dial Graduation :



Black graduation on white for single range , Black and red graduation on white for dual ranges



Design Material



Casing and Bezel Ring :



Casing and Bezel Ring , SS304



Sensing Element :



Copper alloy



Connection :



Brass



Window :



Tempered glass ( SM1SB Series )



Window gasket :



Industrial rubber seal



Pointer :



Black painted aluminium



Dial Plate :



Aluminium alloy



Mounting Code :



L:Bottom entry, W:Bottom with back flange, B:Back entry(centre-back,cower-back)

F:Back with front flange, Z:Back with bracket



FAQ



Q: What ' s your business scope ?
A: High qulaity industry instruments is our business scope .Include Flow meter,Water meter,Manometer,Pressure ,Temperature,Level transimitter and parts.and industry Valve for water,anticorrosion fluid .



Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .

Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .



Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample .



Why choose us


1: Various style for each products and completely series industry instruments.
2: Large stock for fast shipping .

3: Sample order & small quantity order is acceptable .
4: Customize according to your special request .
5: Provide free products information .Digital Liquid Filled Pressure Gauge / Liquid Filled Oil Pressure Gauge Back And Bottom Entry
